TrailMaster iMini Electric Go Kart
DISCONTINUED
The TrailMaster iMini Electric Go Kart has been discontinued. Please go here to see our new- Trailmaster cheetah i6 electric go-kart
TrailMaster is excited to introduce the iMini, the electric version of our best-selling Mini XRX/R+.
This model keeps the same physical dimensions as the Mini XRX/R+.
It is powered by a 48V 1.2KW electric motor and a 48V 20Ah battery.
This fully automatic go-kart with reverse offers two forward driving modes.
"H" mode has a top speed of 18 mph, while "L" mode has a top speed of 12 mph.
On a full charge, the TrailMaster iMini Electric Go Kart can travel up to 30 miles.
Designed with safety and performance in mind, the imini features a digital monitor.
The driver must hit the brake before engaging the throttle pedal for added safety.
It also delivers strong low-end torque and can climb slopes up to 15 degrees.
The 5-point safety harness seatbelt, remote start/kill, and padding over the roll cage help ensure a secure ride.
Additional features include an LED headlight, horn, and large tires for superior traction.
Front tires are 145/70-6, and rear tires are 16x8-7.
The rack and pinion steering wheel and hydraulic disc brake provide precise control and quick stops.
The adjustable sports seat has a pedal-to-seat back range of 30 to 35 inches.
It accommodates children aged 4 to 12 years.
The trailmaster iMini combines the familiar features of the Mini XRX/R+ with the eco-friendly benefits of electric power.
It offers a thrilling and safe ride for young adventurers.
Key features of the TrailMaster iMini Electric Go Kart:
- Powered by 48V, 20A battery
- Digital monitor
- Fully automatic with reverse
- Driver has to hit brake in order to engage throttle pedal for safety
- Offers two driving mode: with “H” mode top speed only 18M/h; with “L” mode top speed 12M/h
- Strong low-end torque and able to climb 15 degrees slope
- Driving range up to 30miles
- 5-Point safety harness seatbelt
- Remote Start/Kill
- LED headlight
- Horn
- Big tires: F / R: 145/70-6 / 16x8-7
- Rack and pinion steering wheel
- Hydraulic disc brake
- Padding over roll cage
- Adjustable sports seat: pedal to seat back adjustable from 30 to 35 inches
- Age group: 4 to 12 yrs
SPECIFICATIONS
| Battery Information | |
| Battery: | Lead Acid Battery |
| Nominal Voltage: | 48V |
| Rated Capacity: | 20Ah |
| Charging Temp Range: | 32 °F to 104 °F |
| Storage Temp Range: | 5 °F to 104 °F |
| Charging Time: | 6-8h |
| Range: |
30 miles max depending on weight, speed and driving conditions. |
| Battery model: | 6-DZF-12 |
| Battery Warranty: | 6 months Limited |
| Electric Motor Information | |
| Service Voltage: | 48V |
| Rated Power: | 1.2KW |
| Rated Speed: | 3800RPM |
| Rated Current: | 14A |
| Max Torque: | >=8Nm |
| Current limit: | 30A |
| General Information | |
| Suspension, F / R: | Double A-arm / Double Oil Damped Shock |
| Brakes: | Rear Hydraulic Disc brake |
| Tires, F / R: | 145/70-6 / 16x8-7 |
| Gross Weight: | 273 lbs |
| Net Weight: | 225 lbs |
| Max Load: | 330 lbs |
| Driving Mode: | R-N-D |
| Max speed: | 12mph on “L” mode; 18mph on “H” mode |
| Climbing ability: | 15 degrees |
| Dimension Information | |
| Wheelbase: | 42 inches |
| OA L x W x H: | 67x44x51.2 inches |
| Height to Seat: | 10.2 inches |
| Min Ground Clearance | 2.8 inches |
| Pedal to seat back: | 30 to 35 inches |
| Crate size: | 60X30X21 inches |
